Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague

Product Categories
Top Fencing Co.Limited
Contact Now

Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague

  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18
  • 19
  • 20
  • 21
  • 22
  • 23
  • 24
  • 25
  • 26
  • 27
  • 28

Brand Name : LNF-Chain link Fence Panels

Model Number : 4'6'8' Height

Certification : ASTM

Place of Origin : American Design China Made

MOQ : 1700 liner ft

Price : 4.00$/liner ft

Payment Terms : TT30% deposit balance 70% at sight of finished products

Supply Ability : 10000 liner ft

Delivery Time : 7 work days

Packaging Details : All metal Pallets

Materials : Q235 Steel Pipes and Wire

Mesh Opening : 2”x2/”(50mm x 50mm) 2¼”x2¼”(57mmx57mm) 2⅜x2⅜(60mmx60mm) 2½”x2½” (63mmx63mm)

Diameter : 10ga/3.2mm ,10.5ga/3.00mm ,11ga/2.90mm,11.5ga/2.75mm,12ga /2.60mm 12.5ga/2.5mm 13ga/2.3m

Type : Chain mesh

Tubing : 1¼”(32mm) 1⅜”(35mm) 1½”(38mm) 1⅗”(40mm) 1⅝”(42mm) 1⅞”(48mm)and so on

Warranty : 5-15 years depand on treatment

Customized : Available

Size : 6ftx10ft ,6ftx8ft,6.5ft x 9ft etc

Accessoires : Top Couper

Contact Now

Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague

Chain Link Fence Panels /Construction Fence Panels Spec
Tubing
1¼"(32mm) 1⅜"(35mm) 1½"(38mm) 1⅗"(40mm) 1⅝"(42mm) 1⅞"(48mm)and so on
Thickness of Tubing
14ga/2.00mm 14.5ga/1.90mm 15ga/1.80mm 15.5ga/1.70mm 16ga /1.6mm 16.5ga/1.50mm 17ga1.42mm 18ga 1.22mm
Chain mesh aperture
2"x2"/(50mm x 50mm) 2¼"x2¼"(57mmx57mm) 2⅜"x2⅜"(60mmx60mm) 2½"x2½"(63mmx63mm)
Height
4ft/1220mm 6ft/1820mm 8ft/2420mm
Width
12ft /3650mm was wide acceptance by market also 8ft 9ft 10ft 14ft
Panels Size
6ft x 12ft ,8ft x 12ft, 4ft x 12ft and so on
Diameter /Gauge
10ga/3.2mm ,10.5ga/3.00mm ,11ga/2.90mm,11.5ga/2.75mm,12ga /2.60mm 12.5ga/2.5mm 13ga/2.3m
Base Optional 1
36" length x 30" width x 8"Height /914mmx762mmx203mm
Base Optional 2
36" length x 16" width x 8" Height /914mmx406mmx203mm
Base Optional 3
30" length x 18" width x 8" Height /762mm x460mm x203mm
Standard
ASTM A392-06
Steel
Galvanized Steel Construction
Finish
Corrosion-Resistant Zinc Coating
Transport Packing
Metal pallet Wrapped with Plastic
HDG zinc thickness
14 microns 100gram/SQM 28 microns 200 gram/SQM 42 microns 300 gram/SQM and 84 microns 600 gram/SQM
  • 1⅝" / 1.625inch /41.20mm outer tubing wall thickness 16Ga/1.60mm wall thick 6'x12'
  • 1¼" / 1.250inch/ 32.00mm outer tubing wall thickness 16Ga/1.60mm wall thick 8'x12'
  • 1⅗"/ 1.60inch/ 40.00mm outer tubing wall thickness 16Ga/1.60mm wall thick 4'x12'
  • 1-3/8' tubing 35mm outer diameter frame temporary chain link fencing panels
Hot dipped galvanized 1.2 oz/ft2,1.8 oz/ft2,2 oz/ft2 are standard galvanized but due to market reason so in quoted we are also quoted hot dipped galvanized 100gram/sqm 300gram/sqm and 600gram/sqm to client
for reference and compare price
installing a fence is a costly and labor-intensive project, and you don’t need long-term fencing for construction sites or events. Temporary fence rentals give you the option to place fencing temporarily, provide a solid barrier, and protect your site without a permanent fence structure.
Application
On construction sites and at festivals, safety is usually your top concern. And temporary fencing is a critical component to your safety plan. In fact, it is considered so important to the safety of a construction site, that fencing is required under state and federal laws. It also helps minimize your liability, and your insurance costs, if an accident occurs.

Temporary fencing also helps with outdoor events. Rent event fencing to set up parameters for the event to ensure only paid or invited guests participate. It also helps with crowd control. Not only does it keep people in safe areas, but temporary fencing can set apart VIP areas, keep restrooms more secluded, or to protect talent from excited fans.
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
Specification
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
Temporary Fence Common Specification
Wire Diameter
3.2mm,3.5mm,4.0mm,4.5mm or as request
Opening Mesh
60*150mm,75*75mm,75*100mm,50*100mm etc
Fence Frame Pipe
32mm,38mm,40mm,42mm,48mm etc
Regular Size
2.1*2.4m,1.8*2.4m,2.1*2.9m,or as request
Plastic Feet
600*220*150mm,or 580*245*130mm
Surface Treatment
Hot-dipped galvanized or electric galvanized
Part
Welded mesh Panel,Round Tube Frames,Plastic feet clamp,Stay/Support
Temporary Fence Popular Size
Wire Diameter
3mm
Opening Mesh
60*150mm
Vertical Pipe Size
32*2.0mm,150mm left at top and bottom
Panel Size
2100*2400mm
Horizontal Pipe Size
32*2.0mm
Base Plate
600*220*150mm
Part
Welded mesh Panel,Round Tube Frames,Plastic feet clamp,Stay/Support
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
Temporary Fencing Feet
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
Temporary Fencing Clamps
Temporary Chain Link Fence Panels Size optional /Customized available
  • 4'x9.5'
  • 6'x9.5'
  • 8'x9.5'
  • 4'x12'
  • 6'x12'
  • 8'x12'
  • 6'x14'
  • 8'x14'

Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gagueChain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague

TEMPORARY FENCE BASE -TOPFENCE001STEEL BASE
Size1
36"length x30" widthx8"Height /914mmx762mmx203mm
Size2
36" length x16" widthx8" Height /914mmx406mmx203mm
Size3
30" length x 18" width x 8" Height /762mm x460mm x203mm
Finish
Available hot dipped galvanized or pr-galvanized 100gram-600 gram/SQM
Color
After powder coated available all color
Packing
Metal pallet wrapped with plastic film
Feature
Temporary Chain Link Fence Base
Materials
HDG steel all ARC full welding
Photos
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
Chain Link Fence Panels 6' x 14' cross brace mesh 57mm x 57mm x 2.8mm wire tube 1½"(38mm) x 16 gague
